S:FLEX High-bead rail HK 125 XL 50 / 100

Raised bead rail for trapezoidal sheet metal roofs

Data

  • Application:
    Trapezoidal sheet metal

  • Connection:
    Thin sheet metal screws or rivets on high beads

  • Roof pitch:
    max. 20°.

  • Module type:
    framed modules

  • Module orientation:
    transverse

  • Mounting type:
    Direct clamping, floating mounting

Advantages

  • Low material/assembly costs

  • Rail heights of 50 or 100 mm guarantee sufficient distance to the roof covering for optimum rear ventilation and use at
    high temperatures

  • Floating installation with clamps reduces the number of expansion joints and enables optimum utilization of the roof area

  • High bead rails covered with protective fleece

  • Staples pre-drilled and covered with EPDM sealing tape

Components

Quickly installed with minimal invasive procedures

The installation of photovoltaic systems on corrugated and trapezoidal sheet metal roofing as well as on pantile sheet metal roofs is not only a secure form of anchoring with the S:FLEX pitched roof racks, but also means maximum protection of the roof cladding function, flexible configuration options and maximum cost efficiency.

Thanks to our various systems, we have the right installation option for almost every pitched roof as well as for slightly sloping roofs.

Our project engineers and structural engineers will also find individual solutions for requirements such as very exposed locations and steep alignments that cannot be covered with our standard installation systems. Get in touch with us!
